FeiyuTech VLOG pocket2 3-Axis Joystick Zoom Foldable Handheld Smartphone Gimbal - Born To Be Tiny, Simpler, Smoother and More Practical
Hurry up! Sale Ends indayshoursminssecs
Compatible Dimension: Smartphone width ranges from 41-89mm;
Max Payload: 0.55lb/250g
Compatible Phone: Vlog Pocket 2 is compatible with all smartphones under 6.6 inches, include all iPhone series, all Android series, and smartphones of other systems, such as HUAWEI P30 pro, MI 9, VIVO NEX, OPPO find X, Samsung Note9, etc.
|Battery||7.4 V, 1300MAH, 9.62 Wh, Built-in rechargeable battery 1 Pcs. The gimbal can be charged by Type-C port on the handle while using.|
|Battery Life||9h（when the load is 150g）|
|Charging Time||≥ 1.5h,we advise using 5V/2A adapter. (Forbid to use fast charging adapter) The indicator light is red when charging, and green when fully charged.|
|Controlling Smartphone||The gimbal can directly control photo/video on smartphone original camera, at the same time, zoom, AI Tracking and other functions on Feiyu ON APP by Bluetooth connection.|
|Material||PC, PA6 and other high-strength and high-temperature resistant materials. The temperature is in the range of -45 ° ~ 135 °. The material has high strength material characteristics|
|Colors||Midnight black & Dreamy pink|
|Rotatable Range||Tilt Range：165°
|Weight||272g（not including smartphone）|
|Extensible Port||1/4 inch screw hole on the bottom|
|Standard Accessories||Type-C Cable*1（for charging）、Mini Tripod*1,Portable bag*1|
|Optional Accessories||Adjustable extension rod(with 1/4 inch screw), universal tripod(1/4 inch screw hole)|
|Landscape Switching||Hold the gimbal normally and turn the handle left or right to invert. The roll axis will rotate automatically to avoid that the lens is blocked. The inverted holding can be used for low angle shooting. Before operating, we advise double-tapping the trigger button to recenter the gimbal.|
|Function Mode & Button Operation||Three working modes: Pan Mode, Follow Mode, and Lock Mode.
Power Button(on the side）
|Clearing Bluetooth Info||Move the Joystick upward at the same time double-tap the Power Button to clear Bluetooth pairing info. Restart the Gimbal so that the Bluetooth can be connected again.|
|Exhibition Mode||Move the Focus Button down at the same time five-tap the Trigger Button to enter Exhibition Mode. Double-tap the Trigger button to quit.|
|Operational Function for Users||
Please check the indicator light:
Case 1: After turning on the gimbal, the indicator light turns solid red immediately, the motors don’t work and the gimbal beeps.
Make sure to unlock all the axis, then hold the gimbal handle and triple press the function button to wake it up, or reboot the gimbal by holding the power button.
Case 2: The indicator flashes red light and the gimbal shutdown automatically. This means the battery is low and needs to be charged. Case 3: The indicator will not light up when holding the power button. Plugin the USB charger and see if indicator lights up, if yes, charge it until it turns green. If not, the gimbal is faulty. Case 4: The indicator flashes blue quickly. This means gimbal is faulty and needs repair.
Make sure the smartphone weights less than the maximum payload of the gimbal, mount the phone on the center and then move left or right to make it balanced.
(If not well balanced, The motors will consume additional power for balancing)
If there is green light flashes periodically (which means connected state), please disconnect with previous connected device, or push down the joystick and double-click the power button to clear the Bluetooth pairing, and then restart the gimbal and try connecting again.
Please clear up the Bluetooth connection on gimbal, restart the gimbal and connect again.
Supports controlling the native camera APP to take photos and record videos. It does not support switching between photo mode and video mode.
Third-party camera APP is supported if pressing the volume up button can take a photo.
Single press the M button to switch between 2 modes, which by default are pan follow mode and pan&tilt follow mode.
These 2 modes can be customized, choosing from pan&tilt mode, pan mode, all follow mode and Inception mode.
The rotatable range of the tilt axis is -40° to 40°, exceeding the range will cause the pan axis to shake.
You can calibrate the gimbal by initializing it:
Tap the function button 5 times and wait until the indicator flashes blue light 3 times at a time, tap the function button again to wake it up.
After finishing the initialization, the gimbal will be in pan&tilt follow mode.
